Q2
QIDI Box
Plus 4
Q1 Pro
X-Max 3
Compare QIDI printers
Basic Info
Printing Technology
Fused Deposition Modeling
Print Size (WDH)
390 * 390 * 340 mm
Dimensions
558 * 578 * 612 mm
Package Dimensions
700 * 710 * 750 mm
Net Weight
40 kg
Gross Weight
49.5 kg
Printing Technology
Fused Deposition Modeling
Print Size (WDH)
270 * 270 * 256 mm
Dimensions
402 * 438 * 494 mm
Package Dimensions
480 * 520 * 585 mm
Net Weight
Q2: 18.1 kg
Gross Weight
Q2: 23.5 kg
Printing Technology
Fused Deposition Modeling
Print Size (WDH)
305 * 305 * 280 mm
Dimensions
505 * 487 * 550 mm
Package Dimensions
580 * 600 * 650 mm
Net Weight
Plus4: 27 kg
Gross Weight
Plus4: 32 kg
Body / Structure
XY Structure
CoreXY
X Axis
High Hardness Linear Guide Rail, Belt tensioned automatically
Y Axis
12mm High Hardness Linear Steel Shafts
Z Axis
Independent 2mm lead screw motors*2, 12mm Linear Steel Shafts*4
X/Y Belt / Motor
1.5GT 10mm Width Belt, FOC Closed-loop Stepper Motor
XY Structure
CoreXY
X Axis
High Hardness Linear Guide Rail, Belt tensioned automatically
Y Axis
8mm High Hardness Linear Hollow Steel Shafts
Z Axis
Dual Independent Lead Screw Motors, 10mm linear shafts*4 and screws*2
X/Y Belt / Motor
1.5GT 6mm Width Belt, 42-48 High-Speed Motor
XY Structure
CoreXY
X Axis
10mm High hardness linear hollow steel shafts, Belt tensioned automatically
Y Axis
10mm High hardness linear hollow steel shafts
Z Axis
Dual Independent Lead Screw Motors, 10mm linear shafts*4 and screws*2
X/Y Belt / Motor
1.5GT 9mm Width Belt, 42-48 High-Speed Motor
Print Head
Print Head Temp
≤ 370°C
Extruder / Gear
Direct Extruder, Hardened Steel Dual Gears
Print Head Temp
≤ 370°C
Extruder / Gear
Direct Extruder, Hardened Steel Dual Gears
Print Head Temp
≤ 370°C
Extruder / Gear
Direct Extruder, Hardened Steel Dual Gears
Hot Bed
Hot Bed Temp
≤ 120°C
Hot Bed Temp
≤ 120°C
Hot Bed Temp
≤ 120°C
Speed
Max Tool Head Speed
800 mm/s
Max Acceleration
30000 mm/s²
Max Tool Head Speed
600 mm/s
Max Acceleration
20000 mm/s²
Max Tool Head Speed
600 mm/s
Max Acceleration
20000 mm/s²
Cool Down
Fans (Hot End, Model, Aux)
4-Pin PWM Fan with RPM Feedback
Motherboard Fan
Closed Loop Control
Chamber Circulation
High-power turbo, Closed Loop Control
Chamber Temp
2nd Gen Up to 65°C, Independent Heating
Air Filter
3-in-1 (G3 Pre + H12 HEPA + Coconut Shell Carbon)
Extruder Cooler
Optional (Polar Cooler required)
Fans (Hot End, Model, Aux)
4-Pin PWM Fan with RPM Feedback
Motherboard Fan
Closed Loop Control
Chamber Circulation
Closed Loop Control
Chamber Temp
2nd Gen Up to 65°C, Independent Heating
Air Filter
3-in-1 (G3 Pre + H12 HEPA + Coconut Shell Carbon)
Extruder Cooler
Optional (Polar Cooler required)
Fans (Hot End, Model, Aux)
Closed-Loop Control（2-Pin PWM Fan with RPM Feedback）
Motherboard Fan
Closed-Loop Control
Chamber Circulation
Closed-Loop Control
Chamber Temp
2nd Gen Up to 65°C, Independent Heating
Air Filter
Activated carbon air filter
Extruder Cooler
Not specified in doc
Sensors
Filament Tangle Det.
Yes (QIDI BOX required)
Filament Run Out
Yes
Automatic Leveling
Loadcell Sensor Integrated into Hotend
Input Shaper / Power Loss
Yes / Yes
AI Camera Detection
Yes (Up to 1080P), Timelapse Supported
Filament Tangle Det.
Yes (QIDI BOX required)
Filament Run Out
Yes
Automatic Leveling
Loadcell Sensor Integrated into Hotend
Input Shaper / Power Loss
Yes / Yes
AI Camera Detection
Yes (Up to 1080P), Timelapse Supported
Filament Tangle Det.
Yes
Filament Run Out
Yes
Automatic Leveling
Proximity Switch Detection Level Sensor
Input Shaper / Power Loss
Yes / Yes
AI Camera Detection
Yes (Up to 1080P), Timelapse Supported
Electronics
Display Screen
5 Inch 800*480 Touch Screen
Storage
32G EMMC and USB2.0 Flash Drive
Camera
Up to 1080P, Timelapse Supported
Status RGB LED
Yes
Connectivity
Wi-Fi, Ethernet, USB
Display Screen
4.3 inch 480*272 Touch Screen
Storage
32G EMMC and USB2.0 Flash Drive
Camera
Up to 1080P, Timelapse Supported
Status RGB LED
No
Connectivity
Wi-Fi, Ethernet, USB
Display Screen
5 inch 800*480 Touch Screen
Storage
32G EMMC and USB2.0 Flash Drive
Camera
Up to 1080P, Timelapse Supported
Status RGB LED
No
Connectivity
Wi-Fi, Ethernet, USB
Filament
Supported Filaments
Wide range (PLA, ABS, PETG, TPU, PA-CF, etc.)
Supported Filaments
Wide range (PLA, ABS, PETG, TPU, PA, PC, Carbon/Glass Fiber, etc.)
Supported Filaments
Wide range (PLA, ABS, PETG, TPU, PA, PC, Carbon/Glass Fiber, etc.)
Power Supply
Rated Power
150W+500W(Chamber Heating)+700W(Heatbed)
Rated Power
150W + 280W(Chamber Heating)+200w(Heatbed)
Rated Power
150W + 400W(Chamber Heating)+300W(Heatbed)
WiFi
Wifi Frequency Bands
2.4 GHz / 5 GHz
Wifi Frequency Bands
2.4 GHz
Wifi Frequency Bands
2.4 GHz
